Controlled temperature
Water bath heat exchange supports 5-98 C operation for heating, holding, or cooling workflows.
Mixing and Fermentation Vessel
Water Bath Mixing & Fermenter Unit
A temperature-controlled vessel for small-batch mixing, pasteurization, fermentation, and formulation work.
Batch volume
3 L, 5 L, 10 L, and 15 L vessel options with customized volumes available.
Equipment Role
Built for process decisions, not display-room demonstrations
The water bath mixing and fermenter unit supports small-batch product development where gentle heat exchange, mixing profile, and temperature stability matter. It can be configured for formulation, pasteurization, fermentation, and controlled holding tests.
Flexible mixing
Interchangeable agitator blades help compare shear, suspension, and blending behavior.
Compact development
Small vessel options keep trial size manageable while preserving process control.
Configuration Notes
Specify the module around the trial evidence you need
Strong equipment selection starts with product behavior, utility limits, cleaning expectations, and the measurements required for scale-up.
Select agitation by product behavior
Viscosity, particles, aeration sensitivity, and shear risk should guide blade selection.
Specify heat-up and cool-down needs
Utilities, jacket area, and water bath volume affect thermal response.
Plan sampling access
Sampling, pH checks, culture addition, and cleaning access should be built into the workflow.
Technical Snapshot
Key specifications to confirm before quotation
Values below are typical catalog-derived ranges and should be verified against the final process scope, product risk, and utility environment.
| Parameter | Typical specification |
|---|---|
| Temperature range | 5-98 C |
| Vessel volume | 3 L, 5 L, 10 L, 15 L, or customized |
| Heat exchange | Water bath and jacketed vessel design |
| Temperature control | PLC-controlled temperature management |
| Material options | 304 or 316L stainless steel |
| Circulation | Integrated circulation pump |
| Agitation | Interchangeable mixing blade options |
| Independent tank control | Optional independent temperature control by tank |
| Typical process | Mixing, pasteurization, fermentation, and holding studies |
Applications
Where this equipment usually creates useful pilot data
Use these application routes as starting points, then refine the configuration around viscosity, particles, heat sensitivity, oxygen exposure, and cleaning difficulty.
Fermented dairy trials
Water Bath Mixing & Fermenter Unit can be configured to support fermented dairy trials trials with controlled process conditions and sample collection.
Sauce and dressing development
Water Bath Mixing & Fermenter Unit can be configured to support sauce and dressing development trials with controlled process conditions and sample collection.
Ingredient hydration
Water Bath Mixing & Fermenter Unit can be configured to support ingredient hydration trials with controlled process conditions and sample collection.
Small-batch pasteurization
Water Bath Mixing & Fermenter Unit can be configured to support small-batch pasteurization trials with controlled process conditions and sample collection.
Formulation screening
Water Bath Mixing & Fermenter Unit can be configured to support formulation screening trials with controlled process conditions and sample collection.
Temperature-hold studies
Water Bath Mixing & Fermenter Unit can be configured to support temperature-hold studies trials with controlled process conditions and sample collection.
RFQ
Discuss a Water Bath Mixing & Fermenter Unit configuration
Prepare product type, batch size, target throughput, temperature or pressure range, cleaning requirements, utilities, and the data you need from the trial.
Send an RFQ brief
A concise RFQ brief helps turn this equipment page into a usable configuration discussion.
