Integrated workflow
Combine preparation, thermal processing, homogenization, filtration, filling, and cleaning in one pilot environment.
Integrated Pilot Plant Line
Pilot Plant for Dairy and Juice R&D
An integrated pilot plant platform for dairy, juice, beverage, and ingredient process development.
Line capacity
Modular process coverage from 20-500 L/h, depending on thermal, mixing, filling, and preparation configuration.
Equipment Role
Built for process decisions, not display-room demonstrations
The dairy and juice pilot plant brings multiple R&D process steps into one configurable platform. It can support raw material preparation, mixing, pasteurization, UHT processing, homogenization, filtration, deaeration, dosing, filling, CIP, SIP, and batch data review.
Flexible capacity
20-500 L/h design range supports formulation work, customer samples, and scale-up validation.
Data-led scale-up
PLC operation, touchscreen controls, batch records, and exportable data support process decisions.
Configuration Notes
Specify the module around the trial evidence you need
Strong equipment selection starts with product behavior, utility limits, cleaning expectations, and the measurements required for scale-up.
Build by process route
Start from the required product path, not from a generic equipment list.
Separate must-have from future-ready
Clarify which modules are needed now and which interfaces should be reserved for later expansion.
Define campaign operation
Cleaning time, product changeover, sample points, and data export format affect day-to-day usability.
Technical Snapshot
Key specifications to confirm before quotation
Values below are typical catalog-derived ranges and should be verified against the final process scope, product risk, and utility environment.
| Parameter | Typical specification |
|---|---|
| Capacity range | 20-500 L/h, configuration dependent |
| Thermal processes | Pasteurization, HTST, and UHT options |
| Preparation modules | Washing, extraction, formulation, mixing, blending, and dosing options |
| Texture modules | Inline homogenization and filtration options |
| Oxygen management | Vacuum deaeration option |
| Filling | Pilot filling and aseptic sample filling options |
| Cleaning | CIP and SIP capable process routes |
| Controls | PLC and touchscreen with data export |
| Format | Modular compact skid system |
Applications
Where this equipment usually creates useful pilot data
Use these application routes as starting points, then refine the configuration around viscosity, particles, heat sensitivity, oxygen exposure, and cleaning difficulty.
Dairy beverages
Pilot Plant for Dairy and Juice R&D can be configured to support dairy beverages trials with controlled process conditions and sample collection.
Juice and nectar
Pilot Plant for Dairy and Juice R&D can be configured to support juice and nectar trials with controlled process conditions and sample collection.
Plant-based drinks
Pilot Plant for Dairy and Juice R&D can be configured to support plant-based drinks trials with controlled process conditions and sample collection.
Tea and coffee beverages
Pilot Plant for Dairy and Juice R&D can be configured to support tea and coffee beverages trials with controlled process conditions and sample collection.
Functional drinks
Pilot Plant for Dairy and Juice R&D can be configured to support functional drinks trials with controlled process conditions and sample collection.
Ingredient process validation
Pilot Plant for Dairy and Juice R&D can be configured to support ingredient process validation trials with controlled process conditions and sample collection.
RFQ
Discuss a Pilot Plant for Dairy and Juice R&D configuration
Prepare product type, batch size, target throughput, temperature or pressure range, cleaning requirements, utilities, and the data you need from the trial.
Send an RFQ brief
A concise RFQ brief helps turn this equipment page into a usable configuration discussion.
